Automatic Ultrasonic Printhead Cleaner

Application:
For all types of industrial printheads, such as XAAR128, 126,
500, 382, Seiko SPT255, 510, 1020, Konica256, 512, and Spectra,
Polaris printheads, etc...
Description:
It
is a professional model, it has both the pressure cleaning and
ultrasonic cleaning functions, and is suitable for many kinds of
print heads, such as XAAR, SEIKO, SPECTRA, KONICA, EPSON etc.
Usually it can be clean in a few minute and back to work again
like usual before it was. To make printhead service life longer.
Technical Parameters:
1)
Ultrasonic Frequency: 40KHz
2)
Voltage of the Power supply: AC220V
50Hz
3)
Input Power: P<150W
4)
Types of the spray nozzle that can
be cleaned: XAAR, SEIKO, SPECTRA,
KONICA, EPSON etc.
User Guide:
1)
SET Move the
cursor, press the cursor and it will
move to a new adjustable position
2)
TAP Adjust the
value in the cursor's position,
Press the"Tap"key and the value of a
adjustable position will change from
the current one.
3)
U (Ultrasonic)
Ultrasonic control (start and adjust
the duration of the ultrasonic,
Every press on the button the work
time of the ultrasonic will increase
1, and the range is between 00-24.
When the work hours is 00, it means
the ultrasonic is off, the other
number means the ultrasonic is on.
4)
UP Control the
elevator moving up. (when the
elevator move to the highest
position, the button will lost its
function provisionally.)
5)
DOWN Control the
elevator moving down. (When the
elevator move to the lowest
position, the button will lost its
function provisionally)
¡¡
|
